494 SERIES: KVM Extender for for DVI-D or DVI-I/VGA

The Draco ultra 494 series of extenders offer long distance transmission of DVI-I (DVI or VGA) over Cat-X or fibre optic cabling. The units can extend DVI or VGA video signals with perfect quality up to 10km over fibre or up to 140m over cat-X cables. Images are displayed without delay, brilliantly clear and in perfect resolution quality. These extenders use an optimized compression technology to deliver perfect transmission of 24-bit digital video at 2048×1152 @ 60Hz (including 1920×1200 and 1080p video transports). They provide virtually lossless image quality. Additionally, they can accept separate USB 2.0, analog or digital audio and RS-232 or RS-422 data. Audio options for the vario cards include AES/EBU and S/PDIF up to 96kHz. Unit connection options for audio include mini-XLR, RCA or TOSLINK supporting Dolby Digital, DTS and PCM. Other optional features such as redundant path for critical path requirements and redundant power options make the series 494 the most convenient and economical solution available. The same card can be offered in a 2-slot, 4-slot, 6-slot, and 21-slot frame. Each frame includes the option for redundant power in 100-220VAC or integrated 12VDC, 24VDC, or 48VDC power.
