491 Series: KVM Extender for HDMI 1.x
The Ultra 491 series for HDMI is offered in full HD or Ultra HD models.
Full HD supports video resolutions up to 1920×1080@60Hz and the Ultra HD supports video resolutions up to 4096×2160@30Hz. The units can extend HDMI video signals and USB-HID for keyboard and mouse with perfect quality up to 10km over fibre or up to 140m over cat-X cables. Other data signals supported are USB 2.0, Digital Audio, Analog Audio and RS-232. The 491 series can be used for simple point-to-point applications or in combination with any of the Enterprise or Flex matrix switches to support a more flexible distribution system for HDMI signals. The optimized compression technology delivers perfect transmission of computer video images and offers one of the most flexible packaging options on the market. From a basic 2 slot chassis, the same card sets can be offered in a 4-slot, 6-slot or 21-slot frame.
Features of the 491 Series KVM for HDMI 1.x
- HDMI - Full HD resolutions up to 1920x1200@60Hz
- HDMI - Ultra HD resolutions up to 4096x2160@30Hz
- USB-HID for keyboard/mouse
- Lockable HDMI cable connector
- Compatible with all Vario/Compact series of extenders
- Option – USB 2.0 add-on card
- Option – Analog or Digital Audio
- Option - RS-232 or RS-422 serial interface
- Available in copper or fiber data path connections
- Fits all Draco vario chassis types – optional redundant power available
Technical Specifications for the 491 Series KVM for HDMI 1.x
Input: HDMI w/embedded audio
Output: HDMI w/embedded audio
Resolutions: FHD - VIdeo Resolutions for 1920x1080p60 or 1920x1200@60Hz / 8bit UHD - Video Resolutions for 4096x2160@30Hz
|
Cable Links |
Cat X: 140 m (459 ft) |
|
USB |
USB-HID (standard for keyboard / mouse) |
UP TO 115200 / +/- 5V, CTS, DTR HANDSHAKE
Bi-directional stereo audio, 24bit, 38.4kHz
Compatible with AES/EBU, S/PDIF, Dolby Digital, DTS, PCM, 32-96kHz
